Spherical hyperbolic ceiling slab

How is the spherical hyperbolic plate made

1. Firstly, the board is used to make the module according to the double curvature designed in the drawing

2. Grinding, polishing, cleaning and painting

Specific process of hyperbolic aluminum veneer: adopt appropriate process according to the same curvature shape

According to the drawing, the template shall be rolled by four roll rolling machine in X direction according to the single curved plate process, and the plate surface shall be bent to the required radian by local spot welding in Y direction. According to the initial shape of the template, the workpiece shall be inspected, and the second calibration shall be carried out locally. The surrounding installation edge shall be welded. The special double curved plate shall be of hydraulic type or lifting type

With the diversification of architectural appearance and style, hyperbolic curved plate has been more and more favored by owners and curtain wall designers. However, due to the difficulty in processing hyperbolic plate, few manufacturers can produce aluminum veneer with accurate curved surface, so many projects can only give up the original design scheme,

As a result, the overall effect of the curtain wall is difficult to express the designer's idea. The hyperbolic plate, hyperbolic spherical surface and curved aluminum veneer produced by our company adopt the universal molding machine imported from Germany, the hyperbolic arc drawing machine, and the wood mold machine. With professional curved surface software, we can deepen the drawing and paper model of customers in a very short time

It has high precision, smooth panel surface and precise joints, which fully demonstrates the unique charm of hyperbolic curved plate in metal curtain wall.
